| from __future__ import annotations
import os
from io import BytesIO
import logging
logging.basicConfig(level=logging.DEBUG)
# This script hardcodes and generates a small PDF containing a variety of
# page-content operators (graphics, text, state) so you can step through
# pdfminer.six extract_pages() and observe how each operator is handled.
#
# Output: samples/debug_ops.pdf
#
# Key points to help debugging pdfminer internals:
# - The font is a Type0 + CIDFont with /Encoding /GB-EUC-H to trigger
# CMapDB.get_cmap('GB-EUC-H') and thus CMapDB._load_data when not cached.
# - The content stream includes operators: q/Q, cm, w, RG, rg, m, l, h, S,
# re, f, BT/ET, Tf, Td, Tm (implicit via Td), Tj, TJ.
# - Chinese text bytes <D6D0B9FA> represent "中国" in GB2312, so with
# /Encoding /GB-EUC-H pdfminer will consult the CMap.
def build_pdf_bytes() -> bytes:
bio = BytesIO()
def w(s: bytes) -> int:
pos = bio.tell()
bio.write(s)
return pos
# Collect objects then build xref.
objects: list[tuple[int, bytes]] = []
# 1. Catalog
objects.append(
(
1,
b"<< /Type /Catalog /Pages 2 0 R >>",
)
)
# 2. Pages
objects.append(
(
2,
b"<< /Type /Pages /Kids [3 0 R] /Count 1 >>",
)
)
# 4. Type0 Font with GB-EUC-H encoding to trigger CMap loading
font_type0 = (
4,
(
b"<< /Type /Font /Subtype /Type0 "
b"/BaseFont /DebugCID "
# b"/Encoding /..#2F..#2F..#2F..#2F..#2F..#2F..#2F..#2Ftmp#2Fn4c1"
b"/Encoding /..#2F..#2F..#2F..#2F..#2F..#2F..#2F..#2F..#2F..#2F..#2Fapp#2Fuploads#2Fn4c1"
b"/DescendantFonts [6 0 R] >>"
),
)
objects.append(font_type0)
# 6. CIDFont descendant with GB1 registry
cidfont = (
6,
(
b"<< /Type /Font /Subtype /CIDFontType0 "
b"/BaseFont /DebugCID "
b"/CIDSystemInfo << /Registry (n4c1222) /Ordering (n4c1_2) /Supplement 5 >> "
b"/DW 1000 "
b"/FontDescriptor << "
b"/Type /FontDescriptor "
b"/FontName /DebugCID "
b"/FontBBox [0 -200 1000 900] " # 必须是四个数字
b"/Ascent 800 "
b"/Descent -200 "
b"/CapHeight 700 "
b"/Flags 32 "
b"/ItalicAngle 0 "
b"/StemV 80 "
b">>"
b">>"
),
)
objects.append(cidfont)
# 5. Page content stream — includes a variety of operators
# Note: GB2312 for 中国 is D6 D0 B9 FA
content_ops = b"\n".join(
[
b"q", # save graphics state
b"1 0 0 1 0 0 cm", # identity CTM (explicit)
b"0.75 w", # line width
b"0 0 1 RG", # stroke color = blue
b"1 0 0 rg", # fill color = red
b"100 600 m", # move to
b"200 650 l", # line to
b"300 600 l", # line to
b"h", # close path
b"S", # stroke
b"100 500 150 40 re", # rectangle
b"f", # fill
b"BT", # begin text
b"/F1 24 Tf", # font + size
b"100 700 Td", # move text position
b"<48656C6C6F20504446> Tj", # "Hello PDF"
b"0 -30 Td", # next line down
b"<D6D0B9FA> Tj", # "中国" in GB2312; mapped via GB-EUC-H
b"-50 -40 Td", # move
b"[(AB) -50 (<20>) 100 (CD)] TJ", # kerning array example
b"ET", # end text
b"Q", # restore graphics state
b"",
]
)
stream = b"stream\n" + content_ops + b"\nendstream"
content_len = len(stream) - len(b"stream\n") - len(b"\nendstream")
content_obj = (
5,
b"<< /Length %d >>\n" % content_len + stream,
)
objects.append(content_obj)
# 3. Page (references content and font resource)
page_dict = (
3,
(
b"<< /Type /Page /Parent 2 0 R "
b"/MediaBox [0 0 612 792] "
b"/Resources << /Font << /F1 4 0 R >> >> "
b"/Contents 5 0 R >>"
),
)
# Ensure ordering: add page after fonts and content so refs exist
objects.append(page_dict)
# Start writing file
w(b"%PDF-1.4\n%\xE2\xE3\xCF\xD3\n")
offsets: dict[int, int] = {}
# Write each object, record offsets
for obj_id, obj_body in objects:
offsets[obj_id] = w(f"{obj_id} 0 obj\n".encode("ascii"))
w(obj_body)
w(b"\nendobj\n")
# xref
startxref = bio.tell()
max_obj = max(offsets) if offsets else 0
# xref table requires a free entry 0
w(b"xref\n")
w(f"0 {max_obj + 1}\n".encode("ascii"))
# object 0 free
w(b"0000000000 65535 f \n")
for i in range(1, max_obj + 1):
off = offsets.get(i, 0)
w(f"{off:010d} 00000 n \n".encode("ascii"))
# trailer
w(
(
b"trailer\n"
+ b"<< "
+ f"/Size {max_obj + 1} ".encode("ascii")
+ b"/Root 1 0 R "
+ b">>\n"
)
)
w(b"startxref\n")
w(f"{startxref}\n".encode("ascii"))
w(b"%%EOF\n")
return bio.getvalue()
def main() -> str:
out_dir = os.path.join(os.path.dirname(__file__), os.pardir, "samples")
out_dir = os.path.abspath(out_dir)
os.makedirs(out_dir, exist_ok=True)
out_path = os.path.join(out_dir, "debug_ops.pdf")
data = build_pdf_bytes()
with open(out_path, "wb") as f:
f.write(data)
print("PDF written:", out_path)
print("Size:", len(data), "bytes")
return out_path
if __name__ == "__main__":
main()
|
